XQL660 8 Ton Foam Rubber Cutting Machine CE ISO9001 Rubber Sheet Cutting Machine

Brand Name : HHS

Model Number : XQL-660

Certification : CE,ISO9001

Place of Origin : Shandong, China

MOQ : 1 set

Price : USD:1000-30000 /SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100 sets/month

Delivery Time : 20 working days

Packaging Details : wood package/20-40 gp

Voltage : 220V /380V /440V

Dimension(L*W*H) : 2300X1500X2530

Warranty : 1 Year

Type : Rubber Cutting Machine

Weight : 1000kg

Power(W) : 5.5 KW

Product name : High Quality Vertical Rubber Bale Cutter

Time of blade cutting : 13-16

Contact Now

XQL-660 Rubber Cutting Machine/Rubber Sheet Cutting Machine/Foam Rubber Cutting Machine

1. Main Application

construction of cutting machine : vertical type rubber bale cutter , horizontal type rubber cutter machine

size of vertical type rubber cutter machine : XQL-8T,XQL-12T , XQL-16T, XQL-18T

size of horizontal type rubber cutter machine : 400 , 600, 800 , 1000, 1400

Product Application

1. This machine is suitable for various kinds of rubber material , plastic material and different types not metal material with hardness .

2. The machine owns simple structure , high grade automatic level ,easy operation,little noise ,equipped with safety device, material feeding speed adjustable and so on

3. This machine mainly used for cutting natural rubber ,synthetic rubber into small pieces for plasticating and mixing , it is widely placed near the rubber kneader machine , cutting big rubber material into small pieces for next step

4. The machine mainly consists of cutter , rack , hydraulic station ,machine base ,electrical cabinet ,etc .There is nylon mat on the surface of machine to protect the knife against damage

5. when you need cut the material , just put the material into feeding roller , and feeding roller will feed the material under the knife , then press the motor button in cabinet , knife will fall down and cut the material

2. Technical Parameter

Model	XQL-8T	XQL-12T	XQL-16T	XQL-100T
cutting force	8 T	12 T	16T	98 T
knife of cutter	660mm	880mm	1100mm	10 pieces knife
cutter of stroke	700mm	800mm	1000mm	1100mm
motor	5.5 kw	7.5 kw	11kw	22 KW
speed	20-30mm/s	20-30mm/s	20-30mm/s	110mm/s
machine weight	1000 kg	1200 kg	1500kg	7000 kg

XQL660 8 Ton Foam Rubber Cutting Machine CE ISO9001 Rubber Sheet Cutting Machine

Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…

welcome to visit our factory!
